K2064Rigid couplings one-piece |
go back |
|
Item description/product images |
|
|
DescriptionMaterial:Steel.
Stainless steel 1.4305. Version:Steel black oxidised.
Stainless steel bright.Note:Rigid couplings transmit high torques without rotational play. They are used where there are no shaft displacements or alignment errors. Wear-free and maintenance-free. Screws secured to avoid vibration induced loosening.
The maximum torque transmission can only be achieved through optimal installation and correct shaft dimensions.
Maximum speed 4000 rpm.Temperature range:-40 °C - +175 °C.On request:Other dimensions. DownloadHere is all the information as a PDF datasheet:
Are you looking for CAD data? These can be found directly in the product table.
|
Order No.
| Main
material | C
(DIN 912-12.9) | Tightening
torque of
screws Nm | D1 | D4 | L | R | Nominal
torque
Nm | CAD | Acc. | Price | Order |
|---|
| K2064.1080 | steel | M3x8 | 2,1 | 8 | 24 | 35 | 26,8 | 50 |  | | 0.00 € | | | K2064.1100 | steel | M4x12 | 4,6 | 10 | 29 | 45 | 32,7 | 70 | | | 0.00 € | | | K2064.1120 | steel | M4x12 | 4,6 | 12 | 29 | 45 | 32,7 | 70 | | | 0.00 € | | | K2064.1140 | steel | M5x16 | 9,5 | 14 | 34 | 50 | 39,4 | 190 | | | 0.00 € | | | K2064.1150 | steel | M5x16 | 9,5 | 15 | 34 | 50 | 39,4 | 190 | | | 0.00 € | | | K2064.1160 | steel | M5x16 | 9,5 | 16 | 34 | 50 | 39,4 | 190 | | | 0.00 € | | | K2064.1190 | steel | M6x18 | 16 | 19 | 42 | 65 | 48,2 | 300 | | | 0.00 € | | | K2064.1200 | steel | M6x18 | 16 | 20 | 42 | 65 | 48,2 | 350 | | | 0.00 € | | | K2064.1350 | steel | M8x25 | 39 | 35 | 67 | 95 | 74,1 | 1100 | | | 0.00 € | | | K2064.1250 | steel | M6x18 | 16 | 25 | 45 | 75 | 50,8 | 390 | | | 0.00 € | | | K2064.1300 | steel | M6x18 | 16 | 30 | 54 | 83 | 58,6 | 475 | | | 0.00 € | | | K2064.1400 | steel | M8x25 | 39 | 40 | 77 | 108 | 83,4 | 1325 | | | 0.00 € | | | K2064.1500 | steel | M10x25 | 77 | 50 | 85 | 124 | 93,2 | 2250 | | | 0.00 € | |
| Order No. | Main
material | C
(DIN 912 A2-70) | Tightening
torque of
screws Nm | D1 | D4 | L | R | Nominal
torque
Nm | CAD | Acc. | Price | Order |
|---|
| K2064.2080 | stainless steel | M3x8 | 1,1 | 8 | 24 | 35 | 26,8 | 16 | | | 0.00 € | | | K2064.2100 | stainless steel | M4x12 | 2,5 | 10 | 29 | 45 | 32,7 | 70 | | | 0.00 € | | | K2064.2120 | stainless steel | M4x12 | 2,5 | 12 | 29 | 45 | 32,7 | 70 | | | 0.00 € | | | K2064.2140 | stainless steel | M5x16 | 5,4 | 14 | 34 | 50 | 39,4 | 160 | | | 0.00 € | | | K2064.2150 | stainless steel | M5x16 | 5,4 | 15 | 34 | 50 | 39,4 | 160 | | | 0.00 € | | | K2064.2160 | stainless steel | M5x16 | 5,4 | 16 | 34 | 50 | 39,4 | 160 | | | 0.00 € | | | K2064.2190 | stainless steel | M6x18 | 9,6 | 19 | 42 | 65 | 48,2 | 260 | | | 0.00 € | | | K2064.2200 | stainless steel | M6x18 | 9,6 | 20 | 42 | 65 | 48,2 | 300 | | | 0.00 € | | | K2064.2250 | stainless steel | M6x18 | 9,6 | 25 | 45 | 75 | 50,8 | 325 | | | 0.00 € | | | K2064.2300 | stainless steel | M6x18 | 9,6 | 30 | 54 | 83 | 58,6 | 400 | | | 0.00 € | | | K2064.2350 | stainless steel | M8x25 | 23 | 35 | 67 | 95 | 74,1 | 330 | | | 0.00 € | | | K2064.2400 | stainless steel | M8x25 | 23 | 40 | 77 | 108 | 83,4 | 400 | | | 0.00 € | | | K2064.2500 | stainless steel | M10x25 | 46 | 50 | 85 | 124 | 93,2 | 688 | | | 0.00 € | |
