Item description/product images

DescriptionMaterial:Body polyamide.Version:Body black.Note:Threaded round inserts for attaching levelling feet, swivel feet and castors to round tubes.Assembly:They can be pushed in by hand or tapped in with a plastic hammer.Special features:

DownloadHere is all the information as a PDF datasheet:

Are you looking for CAD data? These can be found directly in the product table.

Datasheet K2031_B Plugs with tapped hole, plastic for square tubes, Form B, rectangular

275 kB

Drawings

Item selection/filter

Order No.	Form	Form definition	A	B	D1	H	L	L1	Load rating max. kN (static load only)	Suitable for
K2031.4020081520	B	rectangular	40	20	M8	5	24	14,5	2	40x20x1,5-2
K2031.4025081520	B	rectangular	40	25	M8	5	24	14,5	2	40x25x1,5-2
K2031.4030081520	B	rectangular	40	30	M8	5	24	14,5	2	40x30x1,5-2
K2031.5020081520	B	rectangular	50	20	M8	5	24	14,5	2	50x20x1,5-2
K2031.5025082530	B	rectangular	50	25	M8	5	24	14,5	2	50x25x1,5-2
K2031.5030081015	B	rectangular	50	30	M8	5	24	14,5	2	50x30x1-1,5
K2031.5030081520	B	rectangular	50	30	M8	5	24	14,5	2	50x30x1,5-2
K2031.6025081520	B	rectangular	60	25	M8	5	24	14,5	2	60x25x1,5-2
K2031.6030081520	B	rectangular	60	30	M8	5	24	14,5	2	60x30x1,5-2
K2031.6040081520	B	rectangular	60	40	M8	5	24	14,5	2	60x40x1,5-2
K2031.4020101520	B	rectangular	40	20	M10	5	24	14,5	2	40x20x1,5-2
K2031.4025101520	B	rectangular	40	25	M10	5	24	14,5	2	40x25x1,5-2
K2031.4030101520	B	rectangular	40	30	M10	5	24	14,5	2	40x30x1,5-2
K2031.5020101520	B	rectangular	50	20	M10	5	24	14,5	2	50x20x1,5-2
K2031.5025102530	B	rectangular	50	25	M10	5	24	14,5	2	50x25x1,5-2
K2031.5030101015	B	rectangular	50	30	M10	5	24	14,5	2	50x30x1-1,5
K2031.5030101520	B	rectangular	50	30	M10	5	24	14,5	2	50x30x1,5-2
K2031.6025101520	B	rectangular	60	25	M10	5	24	14,5	2	60x25x1,5-2
K2031.6030101520	B	rectangular	60	30	M10	5	24	14,5	2	60x30x1,5-2
K2031.6040101520	B	rectangular	60	40	M10	5	24	14,5	2	60x40x1,5-2
K2031.4030121520	B	rectangular	40	30	M12	5	24	14,5	2	40x30x1,5-2
K2031.5030121015	B	rectangular	50	30	M12	5	24	14,5	2	50x30x1-1,5
K2031.5030121520	B	rectangular	50	30	M12	5	24	14,5	2	50x30x1,5-2
K2031.6030121520	B	rectangular	60	30	M12	5	24	14,5	2	60x30x1,5-2
K2031.6040121520	B	rectangular	60	40	M12	5	24	14,5	2	60x40x1,5-2
